• Title: The Delta Distribution Is Not Regular

  • Series: Distributions

  • YouTube-Title: Distributions 6 | The Delta Distribution Is Not Regular

  • Bright video: https://youtu.be/sxoKcJ11BUw

  • Dark video: https://youtu.be/vwsrZ7UWo1c

  • Quiz: Test your knowledge

  • PDF: Download PDF version of the bright video

  • Print-PDF: Download printable PDF version

  • Thumbnail (bright): Download PNG

  • Thumbnail (dark): Download PNG

  • Subtitle on GitHub: dt06_sub_eng.srt

  • Timestamps (n/a)
  • Subtitle in English

    1 00:00:00,270 –> 00:00:02,049 Hello and welcome back

    2 00:00:02,059 –> 00:00:03,559 to distributions.

    3 00:00:03,960 –> 00:00:05,369 And first, as always, I want

    4 00:00:05,380 –> 00:00:06,849 to thank all the nice people

    5 00:00:06,860 –> 00:00:07,909 that support this channel

    6 00:00:07,920 –> 00:00:09,289 on Steady or paypal.

    7 00:00:09,670 –> 00:00:11,130 In today’s part six, we will

    8 00:00:11,140 –> 00:00:12,409 show that the delta

    9 00:00:12,420 –> 00:00:14,189 distribution is not a

    10 00:00:14,199 –> 00:00:15,560 regular distribution.

    11 00:00:16,059 –> 00:00:17,940 So usually we say it’s a

    12 00:00:17,950 –> 00:00:19,329 singular distribution

    13 00:00:19,850 –> 00:00:21,309 more concretely, this means

    14 00:00:21,319 –> 00:00:22,709 there’s no locally

    15 00:00:22,719 –> 00:00:24,370 integrable function F

    16 00:00:25,149 –> 00:00:26,819 defined on RN with

    17 00:00:26,829 –> 00:00:28,600 values in R or C as

    18 00:00:28,610 –> 00:00:30,090 always with the

    19 00:00:30,100 –> 00:00:31,670 property that delta of

    20 00:00:31,680 –> 00:00:33,290 Phi is the same as

    21 00:00:33,299 –> 00:00:34,680 TF of Phi.

    22 00:00:35,349 –> 00:00:36,830 And of course, this property

    23 00:00:36,840 –> 00:00:38,529 should hold for all test

    24 00:00:38,540 –> 00:00:40,509 functions Phi, OK.

    25 00:00:40,520 –> 00:00:42,439 Now, as a reminder TF of

    26 00:00:42,450 –> 00:00:44,310 Phi was defined by the

    27 00:00:44,319 –> 00:00:45,130 integral.

    28 00:00:45,520 –> 00:00:47,200 So we integrate FX

    29 00:00:47,209 –> 00:00:49,130 times Phi X and

    30 00:00:49,139 –> 00:00:50,130 we already showed in the

    31 00:00:50,139 –> 00:00:51,869 last video that for locally

    32 00:00:51,880 –> 00:00:53,360 integral with function F,

    33 00:00:53,369 –> 00:00:54,689 this always defines a

    34 00:00:54,700 –> 00:00:55,650 distribution.

    35 00:00:56,119 –> 00:00:57,389 On the other hand, if we

    36 00:00:57,400 –> 00:00:58,810 put Phi into the delta

    37 00:00:58,819 –> 00:01:00,349 distribution, we get out

    38 00:01:00,360 –> 00:01:01,759 the value of Phi at

    39 00:01:01,770 –> 00:01:02,409 zero.

    40 00:01:02,959 –> 00:01:04,650 Now, our claim here is for

    41 00:01:04,660 –> 00:01:06,459 no F this equality is

    42 00:01:06,470 –> 00:01:07,180 possible.

    43 00:01:07,730 –> 00:01:09,220 Indeed, this is a standard

    44 00:01:09,230 –> 00:01:10,199 exercise.

    45 00:01:10,230 –> 00:01:11,760 And here I want to show you

    46 00:01:11,769 –> 00:01:12,739 the proof of it.

    47 00:01:13,269 –> 00:01:14,459 Let’s do it with a proof

    48 00:01:14,470 –> 00:01:15,720 by contradiction.

    49 00:01:16,339 –> 00:01:17,690 Therefore, let’s assume that

    50 00:01:17,699 –> 00:01:19,230 we find such a function

    51 00:01:19,239 –> 00:01:20,190 F.

    52 00:01:20,199 –> 00:01:21,449 So it’s a locally integrable

    53 00:01:21,750 –> 00:01:23,059 function where we usually

    54 00:01:23,069 –> 00:01:24,389 use this symbol here.

    55 00:01:24,870 –> 00:01:26,559 And now this property here

    56 00:01:26,569 –> 00:01:28,269 will lead to a contradiction.

    57 00:01:28,919 –> 00:01:29,290 OK.

    58 00:01:29,300 –> 00:01:30,739 Now, in the first step, I

    59 00:01:30,750 –> 00:01:32,129 just want to integrate the

    60 00:01:32,139 –> 00:01:33,489 function F itself.

    61 00:01:33,980 –> 00:01:35,790 So we already know this gives

    62 00:01:35,800 –> 00:01:37,279 us a finite number by

    63 00:01:37,290 –> 00:01:39,250 assumption when we integrate

    64 00:01:39,260 –> 00:01:40,690 over a compact set.

    65 00:01:41,339 –> 00:01:42,730 And for this, let’s simply

    66 00:01:42,739 –> 00:01:44,400 choose the unit ball.

    67 00:01:44,800 –> 00:01:46,330 One possibility to describe

    68 00:01:46,339 –> 00:01:47,839 this would be simply to write

    69 00:01:47,849 –> 00:01:49,080 that the Euclidean norm of

    70 00:01:49,089 –> 00:01:50,830 X is less or equal than

    71 00:01:50,839 –> 00:01:51,279 one.

    72 00:01:51,830 –> 00:01:53,389 And in order to get a positive

    73 00:01:53,400 –> 00:01:55,150 number out here, we also

    74 00:01:55,160 –> 00:01:56,959 use the absolute value inside.

    75 00:01:57,709 –> 00:01:59,150 Then we know we get out a

    76 00:01:59,160 –> 00:02:00,519 number A which is a

    77 00:02:00,529 –> 00:02:02,250 finite positive number.

    78 00:02:02,930 –> 00:02:04,069 Now to get an idea of what

    79 00:02:04,080 –> 00:02:05,779 we do here, let’s sketch

    80 00:02:05,790 –> 00:02:07,069 the region where we integrate

    81 00:02:07,080 –> 00:02:08,429 over in the case that the

    82 00:02:08,440 –> 00:02:09,669 dimension is two

    83 00:02:10,399 –> 00:02:11,429 there, we just have this

    84 00:02:11,440 –> 00:02:13,139 circle where we integrate

    85 00:02:13,149 –> 00:02:14,539 over the whole disc.

    86 00:02:15,059 –> 00:02:16,419 Now, what I want to do is

    87 00:02:16,429 –> 00:02:17,660 to go closer to the

    88 00:02:17,669 –> 00:02:19,600 0.0 to the origin

    89 00:02:19,610 –> 00:02:21,250 because this is the one we

    90 00:02:21,259 –> 00:02:22,139 are interested in.

    91 00:02:22,850 –> 00:02:24,520 Therefore, we can take smaller

    92 00:02:24,529 –> 00:02:25,970 and smaller circles here

    93 00:02:26,029 –> 00:02:27,339 and can split up the whole

    94 00:02:27,350 –> 00:02:27,750 region.

    95 00:02:28,419 –> 00:02:29,880 Of course, we do this with

    96 00:02:29,889 –> 00:02:31,580 infinitely many circles

    97 00:02:31,589 –> 00:02:33,169 where we choose one over

    98 00:02:33,179 –> 00:02:34,660 K as the radius.

    99 00:02:35,050 –> 00:02:36,860 So we start with 1/1, then

    100 00:02:36,869 –> 00:02:38,199 comes 1/2

    101 00:02:38,210 –> 00:02:39,979 1/3 and so on.

    102 00:02:40,419 –> 00:02:41,800 And then our idea is that

    103 00:02:41,809 –> 00:02:43,600 we can simply take the union

    104 00:02:43,610 –> 00:02:45,470 of all these rings here.

    105 00:02:45,949 –> 00:02:47,619 And then this infinite union

    106 00:02:47,630 –> 00:02:49,580 is again the whole disc.

    107 00:02:50,160 –> 00:02:50,559 OK.

    108 00:02:50,570 –> 00:02:51,639 I don’t think we need to

    109 00:02:51,649 –> 00:02:53,360 formalize this even more

    110 00:02:53,479 –> 00:02:54,830 because the idea should be

    111 00:02:54,839 –> 00:02:55,320 clear.

    112 00:02:55,929 –> 00:02:57,119 The important thing we get

    113 00:02:57,130 –> 00:02:58,399 is that here at the

    114 00:02:58,410 –> 00:03:00,369 integral, we have a countable

    115 00:03:00,380 –> 00:03:01,000 union.

    116 00:03:01,699 –> 00:03:02,929 And now when you know some

    117 00:03:02,940 –> 00:03:04,619 measure theory or integration

    118 00:03:04,630 –> 00:03:06,149 theory, you immediately know

    119 00:03:06,160 –> 00:03:08,070 what to do because here

    120 00:03:08,080 –> 00:03:09,699 we have a disjoint union,

    121 00:03:10,259 –> 00:03:11,839 we can simply write the whole

    122 00:03:11,850 –> 00:03:13,669 integral as an infinite sum

    123 00:03:13,679 –> 00:03:15,380 over the single integrals

    124 00:03:15,389 –> 00:03:16,380 over the rings.

    125 00:03:16,740 –> 00:03:18,320 Of course, this whole procedure

    126 00:03:18,330 –> 00:03:19,710 here is very natural.

    127 00:03:19,720 –> 00:03:20,869 But it’s the thing we have

    128 00:03:20,880 –> 00:03:22,520 to put in for the integrals.

    129 00:03:23,309 –> 00:03:24,169 In the case, you want to

    130 00:03:24,179 –> 00:03:25,660 learn more about the details

    131 00:03:25,669 –> 00:03:27,169 here, you can simply watch

    132 00:03:27,179 –> 00:03:28,860 my measure theory videos.

    133 00:03:29,490 –> 00:03:31,059 Now the result we get here

    134 00:03:31,070 –> 00:03:32,860 is an infinite sum a series

    135 00:03:32,869 –> 00:03:34,619 which has a finite value.

    136 00:03:35,309 –> 00:03:36,800 Therefore, we can conclude

    137 00:03:36,809 –> 00:03:38,360 that the sequence given by

    138 00:03:38,369 –> 00:03:40,139 these integrals here is a

    139 00:03:40,149 –> 00:03:41,520 sequence that converges to

    140 00:03:41,529 –> 00:03:42,139 zero.

    141 00:03:42,639 –> 00:03:44,220 And we know even more if

    142 00:03:44,229 –> 00:03:45,619 we shift the starting point

    143 00:03:45,630 –> 00:03:47,479 here, we can make this series

    144 00:03:47,490 –> 00:03:48,889 as small as we want.

    145 00:03:49,250 –> 00:03:50,679 For example, we could make

    146 00:03:50,690 –> 00:03:52,539 it smaller than one half

    147 00:03:53,070 –> 00:03:54,929 and I take one half because

    148 00:03:54,940 –> 00:03:56,300 it’s a number that is smaller

    149 00:03:56,309 –> 00:03:57,259 than one.

    150 00:03:57,389 –> 00:03:58,800 And this is what we need

    151 00:03:58,809 –> 00:03:59,860 for the contradiction.

    152 00:04:00,490 –> 00:04:00,869 OK.

    153 00:04:00,880 –> 00:04:02,380 And now we can just summarize

    154 00:04:02,389 –> 00:04:03,210 the whole thing.

    155 00:04:03,270 –> 00:04:04,839 I only did it to show

    156 00:04:04,850 –> 00:04:06,770 you that we find an epsilon

    157 00:04:06,779 –> 00:04:07,949 greater than zero.

    158 00:04:08,380 –> 00:04:09,979 Such that the integral

    159 00:04:09,990 –> 00:04:11,830 over the epsilon ball is

    160 00:04:11,839 –> 00:04:13,809 a number B which is smaller

    161 00:04:13,820 –> 00:04:14,789 than one half.

    162 00:04:15,350 –> 00:04:16,630 So the whole explanation

    163 00:04:16,640 –> 00:04:18,410 told you if we make the

    164 00:04:18,420 –> 00:04:20,190 epsilon ball small enough,

    165 00:04:20,200 –> 00:04:21,910 we can make the whole integral

    166 00:04:21,920 –> 00:04:23,350 as small as we want.

    167 00:04:23,970 –> 00:04:25,380 Of course, this makes totally

    168 00:04:25,390 –> 00:04:26,750 sense if you just think of

    169 00:04:26,760 –> 00:04:28,369 some ordinary functions.

    170 00:04:28,690 –> 00:04:30,549 However, it also holds for

    171 00:04:30,559 –> 00:04:32,359 a locally integrable function.

    172 00:04:32,519 –> 00:04:34,029 Now, this was just a rough

    173 00:04:34,040 –> 00:04:35,369 idea, but I don’t think you

    174 00:04:35,380 –> 00:04:37,019 will have any problems filling

    175 00:04:37,029 –> 00:04:37,950 in the details.

    176 00:04:38,119 –> 00:04:39,670 For example, one detail I

    177 00:04:39,679 –> 00:04:41,149 skipped here is that in this

    178 00:04:41,160 –> 00:04:42,709 union, we will not

    179 00:04:42,720 –> 00:04:44,510 include zero as a point.

    180 00:04:44,760 –> 00:04:45,839 However, since the whole

    181 00:04:45,850 –> 00:04:47,470 integral here does not care

    182 00:04:47,480 –> 00:04:49,049 about a single point, the

    183 00:04:49,059 –> 00:04:50,170 whole calculation is still

    184 00:04:50,179 –> 00:04:50,790 correct.

    185 00:04:51,320 –> 00:04:51,670 OK.

    186 00:04:51,679 –> 00:04:53,290 Now, with this result from

    187 00:04:53,299 –> 00:04:54,829 the first step, we are ready

    188 00:04:54,839 –> 00:04:56,130 to finish the proof

    189 00:04:56,679 –> 00:04:58,250 because we look at the delta

    190 00:04:58,260 –> 00:04:59,609 distribution, it would be

    191 00:04:59,619 –> 00:05:01,410 good to have test functions

    192 00:05:01,420 –> 00:05:02,609 that are concentrated at

    193 00:05:02,619 –> 00:05:03,209 zero.

    194 00:05:03,600 –> 00:05:04,910 Indeed, we already know a

    195 00:05:04,920 –> 00:05:06,769 nice one from part two of

    196 00:05:06,779 –> 00:05:08,769 the video series, it was

    197 00:05:08,779 –> 00:05:10,750 set to zero outside of

    198 00:05:10,760 –> 00:05:12,410 the unit ball and

    199 00:05:12,420 –> 00:05:14,109 inside the unit ball, it

    200 00:05:14,119 –> 00:05:15,769 was given by an exponential

    201 00:05:15,779 –> 00:05:16,209 function.

    202 00:05:16,910 –> 00:05:18,660 This is a nice test function

    203 00:05:18,670 –> 00:05:20,510 and the one dimensional visualization

    204 00:05:20,519 –> 00:05:22,399 would be just such a bump

    205 00:05:23,109 –> 00:05:24,410 where the maximum is

    206 00:05:24,420 –> 00:05:25,989 exactly at zero.

    207 00:05:26,450 –> 00:05:26,790 OK.

    208 00:05:26,799 –> 00:05:27,980 Now you already know from

    209 00:05:27,989 –> 00:05:29,420 the first part, the unit

    210 00:05:29,429 –> 00:05:30,850 ball might be not small

    211 00:05:30,859 –> 00:05:31,529 enough.

    212 00:05:31,540 –> 00:05:32,670 Therefore, we should take

    213 00:05:32,679 –> 00:05:34,200 this epsilon ball here.

    214 00:05:34,649 –> 00:05:35,809 Therefore, I would say let’s

    215 00:05:35,820 –> 00:05:37,329 change the function phi a

    216 00:05:37,339 –> 00:05:39,130 little bit with this epsilon,

    217 00:05:39,549 –> 00:05:41,309 it should be zero outside

    218 00:05:41,320 –> 00:05:43,290 of the epsilon ball and

    219 00:05:43,299 –> 00:05:45,010 inside it should be the same

    220 00:05:45,019 –> 00:05:46,170 exponential function.

    221 00:05:47,059 –> 00:05:48,790 Therefore, also inside the

    222 00:05:48,799 –> 00:05:50,489 exponential function we have

    223 00:05:50,500 –> 00:05:52,070 to divide by epsilon.

    224 00:05:52,579 –> 00:05:53,970 And then you see this was

    225 00:05:53,980 –> 00:05:55,540 just scaling the whole test

    226 00:05:55,549 –> 00:05:56,070 function.

    227 00:05:56,779 –> 00:05:58,010 Everything looks exactly

    228 00:05:58,019 –> 00:05:59,839 the same just zoom to

    229 00:05:59,850 –> 00:06:01,160 the epsilon ball instead of

    230 00:06:01,170 –> 00:06:02,070 the unit ball.

    231 00:06:02,440 –> 00:06:02,670 OK.

    232 00:06:02,679 –> 00:06:04,450 Then let’s calculate with

    233 00:06:04,459 –> 00:06:05,480 this test function

    234 00:06:06,209 –> 00:06:07,869 by assumption this integral

    235 00:06:07,880 –> 00:06:09,420 here is given by the delta

    236 00:06:09,429 –> 00:06:11,029 distribution which means

    237 00:06:11,040 –> 00:06:12,380 it gives us the value of

    238 00:06:12,390 –> 00:06:13,940 the test function at zero.

    239 00:06:14,500 –> 00:06:15,700 It’s a positive number.

    240 00:06:15,709 –> 00:06:17,299 Hence, we don’t change anything

    241 00:06:17,309 –> 00:06:18,869 when we use absolute values

    242 00:06:18,880 –> 00:06:20,420 here, it makes everything

    243 00:06:20,429 –> 00:06:21,790 easier because we can just

    244 00:06:21,799 –> 00:06:23,640 apply the triangle inequality

    245 00:06:23,649 –> 00:06:24,799 for integrals.

    246 00:06:25,269 –> 00:06:26,470 So now we have the absolute

    247 00:06:26,480 –> 00:06:27,929 value inside the

    248 00:06:27,940 –> 00:06:28,640 integral.

    249 00:06:28,920 –> 00:06:30,239 This means that we can just

    250 00:06:30,250 –> 00:06:32,019 pull out the supreme norm

    251 00:06:32,029 –> 00:06:33,119 of the test function.

    252 00:06:33,579 –> 00:06:34,970 However, before we do that,

    253 00:06:34,980 –> 00:06:36,260 we should change the region

    254 00:06:36,269 –> 00:06:38,040 where we integrate over to

    255 00:06:38,049 –> 00:06:39,049 the epsilon ball.

    256 00:06:39,459 –> 00:06:41,170 Because outside of the epsilon

    257 00:06:41,179 –> 00:06:42,609 ball, everything is zero

    258 00:06:42,619 –> 00:06:43,890 by the test function.

    259 00:06:44,239 –> 00:06:45,559 And maybe now you already

    260 00:06:45,570 –> 00:06:47,239 see why we care so much about

    261 00:06:47,250 –> 00:06:48,160 the epsilon ball.

    262 00:06:48,260 –> 00:06:49,829 First, let’s pull out the

    263 00:06:49,839 –> 00:06:51,130 supremum norm of the test

    264 00:06:51,140 –> 00:06:51,779 function.

    265 00:06:52,109 –> 00:06:53,630 And then you see only this

    266 00:06:53,640 –> 00:06:55,250 integral here remains

    267 00:06:55,420 –> 00:06:57,279 first, the supremum here

    268 00:06:57,290 –> 00:06:58,660 we already know it’s the

    269 00:06:58,670 –> 00:07:00,149 value at zero more

    270 00:07:00,160 –> 00:07:01,690 concretely the same as the

    271 00:07:01,700 –> 00:07:02,609 left hand side.

    272 00:07:03,140 –> 00:07:04,660 And the second part here

    273 00:07:04,670 –> 00:07:06,079 is equal to B

    274 00:07:06,380 –> 00:07:08,339 however, B was smaller

    275 00:07:08,350 –> 00:07:10,339 than one half, which

    276 00:07:10,350 –> 00:07:12,220 means we have an inequality

    277 00:07:12,239 –> 00:07:14,000 which can’t be satisfied.

    278 00:07:14,410 –> 00:07:16,019 So we have a positive number

    279 00:07:16,029 –> 00:07:17,820 which does not get smaller

    280 00:07:17,829 –> 00:07:19,059 when we multiply it with

    281 00:07:19,070 –> 00:07:19,799 one half.

    282 00:07:20,290 –> 00:07:21,609 And such a positive real

    283 00:07:21,619 –> 00:07:23,369 number does not exist.

    284 00:07:24,029 –> 00:07:25,769 And this is indeed our wanted

    285 00:07:25,779 –> 00:07:27,440 contradiction in

    286 00:07:27,450 –> 00:07:29,190 conclusion such a locally

    287 00:07:29,200 –> 00:07:30,869 integral function F for the

    288 00:07:30,880 –> 00:07:32,559 delta distribution does not

    289 00:07:32,570 –> 00:07:33,239 exist.

    290 00:07:33,760 –> 00:07:35,570 Therefore, the delta distribution

    291 00:07:35,579 –> 00:07:36,769 is not a regular

    292 00:07:36,779 –> 00:07:37,670 distribution.

    293 00:07:38,019 –> 00:07:38,320 OK.

    294 00:07:38,329 –> 00:07:39,480 Then in the next video, I

    295 00:07:39,489 –> 00:07:40,609 will show you what we can

    296 00:07:40,619 –> 00:07:42,220 really do with distributions

    297 00:07:42,230 –> 00:07:43,399 and how to calculate with

    298 00:07:43,410 –> 00:07:43,980 them.

    299 00:07:43,989 –> 00:07:45,149 Therefore, I hope I see you

    300 00:07:45,160 –> 00:07:46,480 there and have a nice day.

    301 00:07:46,489 –> 00:07:47,160 Bye.

  • Quiz Content

    Q1: Is the delta distribution a regular distribution?

    A1: Yes.

    A2: No.

    Q2: Is there a locally integrable function $f$ such that $\delta = T_f$?

    A1: Yes.

    A2: No.

    Q3: Is the function $\varphi_\varepsilon \in \mathcal{D}(\mathbb{R}^n)$ given by $$\varphi_\varepsilon(x) = \begin{cases} 0 &,~ | x | \geq \varepsilon \ \exp\left( - \frac{1}{1 - |x/\varepsilon |^2 } \right) &,~ | x | < \varepsilon \end{cases}$$ a well-defined test function for $\varepsilon > 0$.

    A1: Yes!

    A2: No!

  • Back to overview page
